SHINING 09063-C-14T Split Sprocket

- Precision Drive Solution for Sugar Mill Chains

14 Tooth Sprocket Features

The SHINING 9063-C-14T split sprocket is engineered for reliable performance in demanding sugar mill applications. Designed with a 14-tooth configuration, this sprocket ensures smooth engagement with sugar mill chains while maintaining optimal power transmission efficiency.

Manufactured from high-quality carbon steel, the sprocket teeth undergo specialized heat treatment to provide superior wear resistance against abrasive materials like bagasse. The precision-machined tooth profile guarantees minimal vibration and reduced chain stress, making it ideal for continuous operation in sugar processing applications.

14 Tooth Sprocket Specifications

• Model: 09063-C-14T Split Sprocket

• Compatible Chain: 09063 Chain

• Tooth Count: 14

• Hub Type: C-Type Double Hub)

• Design: Split Sprocket

• Chain Pitch: 152.4mm

• Pitch Circle Diameter (PCD): Ø684.88mm

• Addendum Circle Diameter (OD): Ø735mm

• Bore Diameter: Ø101.6mm

• Overall Width with Hub: 152.4mm

• Wheel Thickness: 32mm

• Material: High-grade Carbon Steel

• Surface Treatment: Shot Blasting

09063-C-14T Split Sprocket Applications in Sugar Mills

• Bagasse Conveyor Systems

• Intermediate Cane Carriers

• Sugar Mill Elevator Chains

• Material Handling Conveyors

14 Tooth Sprocket Service

SHINING provides comprehensive technical support and custom manufacturing services for sugar mill chain drive systems. With decades of OEM experience, we offer complete lifecycle management to ensure optimal performance of your equipment.

We also provide the 09063-C-15T sprocket and fully customized solutions to meet your specific requirements.

Contact Us Today for Your Sprocket Solutions:

Email our team at [email protected] for customized solutions and expert support.
